Teltonika OTD500
The OTD500 is Teltonika's IP55-rated outdoor 5G router — built to bolt to a wall, mast or roof and forget about. 5G Sub-6 GHz with peak 3.4 Gbps downlink, LTE Cat 19 fallback at 1.6 Gbps, dual-SIM + eSIM auto-switching, and PoE-in/out so you can run power and data over a single Ethernet cable. The kind of unit you specify when the connectivity needs to survive whatever the British weather throws at it.
- Manufacturer
- Teltonika
- Model
- OTD500
- Warranty
- 24 months
Key features
- 5G Sub-6 GHz SA + NSA with peak 3.4 Gbps DL / 900 Mbps UL
- 4G LTE Cat 19 fallback at 1.6 Gbps DL
- Dual-SIM + eSIM with automatic switching
- IP55-rated outdoor housing, integrated mounting bracket
- PoE-in / PoE-out — power and data over one cable
- 6 kV ground-free lightning protection built in
Technical specifications
Cellular
- 5G modes
- SA + NSA
- 5G throughput
- Up to 3.4 Gbps DL, 900 Mbps UL (4×4 MIMO)
- 5G NR bands
- n1, n3, n5, n7, n8, n20, n28, n38, n40, n41, n71, n75, n76, n77, n78
- 4G fallback
- LTE Cat 19 (1.6 Gbps DL / 200 Mbps UL)
- 3G fallback
- WCDMA up to 42 Mbps DL
- SIM slots
- 2× physical + eSIM, auto-switching
Ports
- Ethernet
- 2× Gigabit (1000 Mbps) with PoE-in / PoE-out
- Antennas
- 4× internal
Power
- Powering
- PoE-in (IEEE 802.3at) or local DC
- PoE-out
- For powering a downstream device over the second Ethernet
- Lightning protection
- 6 kV ground-free
Physical
- Ingress protection
- IP55
- Operating temperature
- -40 °C to +55 °C
- Mounting
- Integrated bracket (pole / wall)
Software
- Operating system
- RutOS (OpenWrt-based)
- VPN protocols
- OpenVPN, IPsec, WireGuard, GRE, L2TP, ZeroTier, Tailscale
- Management
- WebUI, SSH, SNMP, Teltonika RMS, SIMSY portal
Compliance
- Certifications
- CE, UKCA (confirm region before deployment)
- Warranty
- 24 months manufacturer
What's in the box
- OTD500 outdoor 5G router (integrated antennas)
- Mounting bracket (pole / wall)
- PoE injector
- Outdoor-rated Ethernet cable
- Quick start guide
Best for
EV charging sites
Mount the unit on the charger canopy or a nearby mast. PoE-out can power a camera or sensor over the second Ethernet. IP55 means it stays put through winters.
Construction and temporary sites
5G uplink for the site office and welfare cabins. Dual-SIM + eSIM means you can pre-provision both before the unit ships and swap operators without a site visit.
Outdoor digital signage and DOOH
Roof-mounted, weather-proof, PoE-powered. Drives the screens, the camera array and the analytics endpoint from one cellular uplink.
Connected agriculture and remote monitoring
Designed for the kind of installations where you don't want to send an engineer out. Robust, remote-managed via Teltonika RMS, observable via the SIMSY portal.
Frequently asked
How is it powered?
What's the PoE-out for?
Will it survive a British winter?
Does it ship with a SIM?
What's the warranty?
